Project Name & Description
Capabilities Applied/Processes
Cut only, Labor Only, Cut and Sew. RF welding, die cutting, die press, stack cutting, single poly CNC cutting.
Equipment Used to Manufacture Part
½” Double needle, 1/4” Double needle, 1” double needle, single needle, juki automatic box-x, RFL welder (heat sealer), CNC single ply cutter, grommet machine.
Overall Part Dimensions
10”x10”x.5”
12”x18”x3”
12”x18”x3”
18”x18”x1”
24”x24”x1”

Custom: Max 6’Lx6’Wx4’H
Tightest Tolerances
± .5”
Material Used
vinyl mesh, 14 oz. vinyl, 18 oz. vinyl, 22 oz. vinyl, laminate, canvak, kevlar, pyrosnuff, #8 canvas, #10 canvas, # 12 canvas, Polyster, Cordura, ballistic, and more custom fabrics
Material Finish
Laminated padded finish, urethan coated, vinyl coated, waterproof seal.
Seam Finish
Nylon Zipper (#5-#10), Molded Zipper (#5-#10), 1/8”-1/4” drawstring, Hook and Loop Fasteners, common sense,lift-a-dot, stainless steel snaps, roll top, 1” side release buckles, and open finish.
Industry for Use
Marine, Transportation, agriculture, manufacturing, production, food processing, navigation, travel, and commercial.
In Process Testing/Inspection Performed
Volume
50+
Delivery/Turnaround Time
Varies. 3 week average
Delivery Location
Urbandale, IA
Standards Met
